CAT.5e 12 Port Wall Mount Panel
ProFIT Patch™
CAT.6 12 Port Wall Mount Panel CAT.6 12 Port Wall Mount Panel.. Product #: Universal LC elite

CAT.6 12 Port Wall Mount Panel

- +

CAT.6 12 Port Wall Mount Panel

Features:
  • Dual IDC Connector can accept 22-26 AWG solid and stranded cables
  • Hot Pluggable
  • 6 pack connectors instead of 8 for higher reliability
  • Supports T568 A&B wiring & easy installation
  • Interoperable and backward compatible to category 5 or 3
  • Mountable on 19” EIA Racks (excludes wall mount 12 port)
Specifications
  • Meets TIA/EIA-568-B.2 Category 5E, ISO/IEC11801 and EN50173-1 specification
  • Safety: UL1863
  • Flammability: UL 94 VO
  • Operating temperature: -40 to +70 degree Celsius
  • Insulation diameter range: 0.70 to 1.40mm
  • Panel Operating Life: minimum 250 re-terminations
  • Connector Operating: Life minimum 750 insertions
  • Contact Material: 0.8mm thickness alloy

    • Click to view or download (PDF Documents)
